Single piece construction, fabricated from carbon
steel structural tubing with uniform wall thickness. Most common configurations listed. Consult Factory for additional options.
Conform to ASTM A500 Grade C with a minimum yield
strength of 50,000 psi.
Anchor base fabricated from hot rolled carbon steel plate
that meets/exceeds minimum yield strength of 36,000 psi.
Handhole is standard on all poles.
Anchor bolts fabricated from hot rolled carbon steel bar that
meets/exceeds a minimum yield strength of 55,000 psi. Anchor
bolts are provided with all poles unless otherwise specified.
The Standard Finish is a polyester thermosetting powder coating
with a minimum of 3 mils. Hot dip Galvanized finish to a ASTM A123
specification also available. Consult factory for alternate finishes.
