GL4c

40,000 to 55,000 lumen Site Lighting

EnergyLite’s GridLite family integrates the latest advancements in LED technology, driving the trend towards smaller and lighter site and area light fixtures. This allows for poles with lower EPA ratings, offering even more savings. The GL1 ranges from 40,000 lumens/300W to 55,000 lumens/440W.

Replaces small and mid-sized area HID fixtures up to 1800W.

  • 120-277V Standard; 347-480V option available
  • Type II Medium, Type III Medium, Type IV Short, Type V Square distributions
  • 0-10V dimming standard; DALI-2 dimming option available
  • Motion sensor option available
  • IP66 rated optical and electrical chambers
  • Adjustable for 1½” to 2½” O.D. tenon
Finish Options
